Alimentare electrica (Ph-V-Hz)
220-240V,1Ph,50Hz
Amperaj incalzire ( A )
6.4(0.9~10.5)
Amperaj racire ( A )
6.9(0.6~10.3)
Compresor Amperaj in functionare ( A )
7.50
Compresor Capacitate ( Btu/h )
4385
Compresor Model
KSN140D21UFZ
Compresor Putere consumata ( W )
1140
Compresor Refrigerant oil/oil charge ( ml )
VG74/ 440ml
Consum electric incalzire ( W )
1480(200~2410)
Consum electric racire ( W )
1539(140~2360)
Control temperatura
Telecomanda
Debit aer UI (Hi/Mi/Lo) (m3/h)
840/680/540
Incalzire sezoniera Clasa eficienta energetica
A+
Incalzire sezoniera Pdesignh ( kW )
4.1
Incalzire sezoniera SCOP (W/W)
4.0
Incalzire sezoniera Temperatura de balans (℃)
-7
Motor ventilator UE Model
ZKFN-40-8-1L-5
Motor ventilator UE Putere ( W )
63
Motor ventilator UE Turatie (r/min)
800/650/550
Motor ventilator UI Condensator electric (uF)
―
Motor ventilator UI Model
WZDK30-38G
Motor ventilator UI Putere ( W )
36
Motor ventilator UI Turatie(Hi/Mi/Lo) (r/min)
1130 / 900 / 800
Nivel presiune sonora UE ( dB(A) )
56.0
Presiune de proiect ( MPa )
4.3/1.7
Presiune sonora UI (Hi/Mi/Lo/Si) ( dB(A) )
44/37/30/25
Putere Incalzire Capacitate ( Btu/h )
19000(4700~23000)
Putere max. consumata ( W )
2950
Putere Racire Capacitate ( Btu/h )
18000
(6200~20900)
Putere sonora UE ( dB(A) )
61.0
Putere sonora UI (Hi) ( dB(A) )
55
Racire sezoniera Clasa eficienta energetica
A++
Racire sezoniera Pdesignc ( kW )
5.2
Racire sezoniera SEER (W/W)
7.1
Refrigerent Masa incarcatura ( Kg )
1.00
Schimbator UI a.Numar spirale
2.0
Schimbator UI a.Numar spirale_1
2.0
Schimbator UI b.Pas tub(a)x pas linie(b) ( mm )
21x13.37
Schimbator UI b.Pas tub(a)x pas linie(b) ( mm )_1
21x22
Schimbator UI c.Spatiere ( mm )
1.2
Schimbator UI c.Spatiere ( mm )_1
1.2
Schimbator UI e.Diametru tub ( mm )
Φ7, tub canelat
Schimbator UI f.Lungime spira x inaltime x latime ( mm )
750x294x26.74
Schimbator UI f.Lungime spira x inaltime x latime ( mm )_1
860x504x44
Schimbator UI g. Numar de circuite
3
Suprafata aplicatie minim maxim (m2)
24-35
Temperatura limita pentru incalzire (℃)
-15
Temperaturi de lucru Exterior (racire/incalzire) ( ℃ )
-15～50/-25～30
Temperaturi de lucru Intern (racire/incalzire) (℃)
17～32/0～30
Tevi refrigerent Diam tevi refrigerent lichid/gaz ( mm/inch )
Φ6.35(1/4’‘)/Φ12.7(1/2’‘)
Tevi refrigerent Diferenta max. de nivel ( m )
20
Tevi refrigerent Lungime maxima traseu teava ( m )
30
UE Ambalaj (W*D*H) ( mm )
920x390x615
UE Dimensiuni (W*D*H) ( mm )
800x333x554
UE Masa Net/Gross ( Kg )
34/36.7
UI Ambalaj (W*D*H) ( mm )
1035x295x380
UI Dimensiuni(W*D*H) ( mm )
957x213x302
UI Masa Net/Gross ( Kg )
10/13
