Alimentare electrica (Ph-V-Hz)
220V-240V,1Ph,50Hz
Amperaj incalzire ( A )
4.2(0.4~6.9)
Amperaj racire ( A )
5.4(0.5~6.9)
Compresor Amperaj in functionare ( A )
4.90
Compresor Capacitate ( Btu/h )
2780
Compresor Model
KSK89D53UEZ
Compresor Putere consumata ( W )
712
Compresor Refrigerant oil/oil charge ( ml )
ESTEL OIL VG74/280ml
Consum electric incalzire ( W )
964(100~1580)
Consum electric racire ( W )
1237(130~1580)
Control temperatura
Telecomanda
Debit aer UI (Hi/Mi/Lo) (m3/h)
600/500/360
Incalzire sezoniera Clasa eficienta energetica
A+
Incalzire sezoniera Pdesignh ( kW )
2.3
Incalzire sezoniera SCOP (W/W)
4.0
Incalzire sezoniera Temperatura de balans (℃)
-7
Model
2023
HYU-12HRFN8-QRD1GW
Motor ventilator UE Model
ZKFN-34-8-1
Motor ventilator UE Putere ( W )
66
Motor ventilator UE Turatie (r/min)
850/650/450
Motor ventilator UI Condensator electric (uF)
1.2
Motor ventilator UI Model
YKFG-13-4-38L-4
Motor ventilator UI Putere ( W )
40
Motor ventilator UI Turatie(Hi/Mi/Lo) (r/min)
1130 / 950 / 750
Nivel presiune sonora UE ( dB(A) )
56.0
Presiune de proiect ( MPa )
4.3/1.7
Presiune sonora UI (Hi/Mi/Lo/Si) ( dB(A) )
40/34/26/22
Putere Incalzire Capacitate ( Btu/h )
13000(3700~14400)
Putere max. consumata ( W )
2150
Putere Racire Capacitate ( Btu/h )
12000
(3800~14200)
Putere sonora UE ( dB(A) )
65.0
Putere sonora UI (Hi) ( dB(A) )
53.0
Racire sezoniera Clasa eficienta energetica
A++
Racire sezoniera Pdesignc ( kW )
3.5
Racire sezoniera SEER (W/W)
6.1
Refrigerent Masa incarcatura ( Kg )
0.5
Schimbator UI a.Numar spirale
2.0
Schimbator UI a.Numar spirale_1
1.0
Schimbator UI b.Pas tub(a)x pas linie(b) ( mm )
19.5x11.6
Schimbator UI b.Pas tub(a)x pas linie(b) ( mm )_1
21x22
Schimbator UI c.Spatiere ( mm )
1.2
Schimbator UI c.Spatiere ( mm )_1
1.2
Schimbator UI e.Diametru tub ( mm )
Φ5, tub canelat
Schimbator UI f.Lungime spira x inaltime x latime ( mm )
595x273x23.2
Schimbator UI f.Lungime spira x inaltime x latime ( mm )_1
680x504x22
Schimbator UI g. Numar de circuite
4
Suprafata aplicatie minim maxim (m2)
16-23
Temperatura limita pentru incalzire (℃)
-15
Temperaturi de lucru Exterior (racire/incalzire) ( ℃ )
-15～50/-25～30
Temperaturi de lucru Intern (racire/incalzire) (℃)
17～32/0～30
Tevi refrigerent Diam tevi refrigerent lichid/gaz ( mm/inch )
Φ6.35(1/4")/Φ9.52/(3/8")
Tevi refrigerent Diferenta max. de nivel ( m )
10
Tevi refrigerent Lungime maxima traseu teava ( m )
25
UE Ambalaj (W*D*H) ( mm )
815x325x615
UE Dimensiuni (W*D*H) ( mm )
700x275x550
UE Masa Net/Gross ( Kg )
22.7/25.2
UI Ambalaj (W*D*H) ( mm )
870x270x360
UI Dimensiuni(W*D*H) ( mm )
805x194x285
UI Masa Net/Gross ( Kg )
7.6/9.7
