Alimentare electrica (Ph-V-Hz)
220V-240V,1Ph,50Hz
Amperaj incalzire (A)
4.05(0.5~5.5)
Amperaj racire (A)
3.48(0.4~5.4)
Compresor Amperaj in functionare (A)
5.70
Compresor Capacitate (Btu/h)
3245
Compresor Model
KSK103D32UEZ31
Compresor Putere consumata (W)
850
Compresor Refrigerant oil/oil charge (ml)
ESTEL OIL VG744 280
Consum electric incalzire (W)
930(120~1200)
Consum electric racire (W)
800(100~1240)
Control temperatura
Telecomanda
Debit aer UI (Hi/Mi/Lo) (m3/h)
435/333/259
Exterior (racire/incalzire) (℃)
-15～50/-20～30
Incalzire sezoniera Clasa eficienta energetica
A+++
Incalzire sezoniera Pdesignh (kW)
2.3
Incalzire sezoniera SCOP (W/W)
5.1
Incalzire sezoniera Temperatura de balans (℃)
-7
Motor ventilator UE Model
ZKFN-25-10-5L
Motor ventilator UE Putere (W)
66
Motor ventilator UE Turatie (r/min)
780/600
Motor ventilator UI Condensator electric (uF)
1.2
Motor ventilator UI Model
ZKFP-30-8-357L
Motor ventilator UI Putere (W)
35
Motor ventilator UI Turatie(Hi/Mi/Lo) (r/min)
1100 / 900 / 750
Nivel presiune sonora UE (dB(A))
55
Presiune de proiect (MPa)
4.3/1.7
Presiune sonora UI (Hi/Mi/Lo/Si) (dB(A))
37/32/25/21.5
Putere Incalzire Capacitate (Btu/h)
10000(2800~11500)
Putere max. consumata (W)
2150
Putere Racire Capacitate (Btu/h)
9000
(3100~11600)
Putere sonora UE (dB(A))
59
Putere sonora UI (Hi) (dB(A))
50
Racire sezoniera Clasa eficienta energetica
A++
Racire sezoniera Pdesignc (kW)
2.6
Racire sezoniera SEER (W/W)
7
Refrigerent Masa incarcatura (Kg)
0.47
Schimbator UI a.Numar spirale
2.0
Schimbator UI a.Numar spirale_1
1.0
Schimbator UI b.Pas tub(a)x pas linie(b) (mm)
19.5x11.6
Schimbator UI b.Pas tub(a)x pas linie(b) (mm)_1
18x17.3
Schimbator UI c.Spatiere (mm)
1.2
Schimbator UI c.Spatiere (mm)_1
1.3
Schimbator UI e.Diametru tub (mm)
Φ5,tub canelat
Schimbator UI e.Diametru tub (mm)_1
Φ5,innergroove tube
Schimbator UI f.Lungime spira x inaltime x latime (mm)
510x78x23.2+510x97.5x23.2+510x78x23.2
Schimbator UI f.Lungime spira x inaltime x latime (mm)_1
745x468x17.3
Schimbator UI g. Numar de circuite
3
Schimbator UI g. Numar de circuite_1
3
Suprafata aplicatie minim maxim (m2)
12-18
Temperatura limita pentru incalzire (℃)
-15
Temperaturi de lucru Intern (racire/incalzire) (℃)
17～32/0～30
Tevi refrigerent Diametru tevi refrigerent lichid/gaz (mm/inch)
Φ6.35(1/4")/Φ9.52/(3/8")
Tevi refrigerent Diferenta max. de nivel (m)
10
Tevi refrigerent Lungime maxima traseu teava (m)
25
UE Ambalaj (W*D*H) (mm)
835x300x540
UE Dimensiuni (W*D*H) (mm)
720x270x495
UE Masa Net/Gross (Kg)
21/22.8
UI Ambalaj (W*D*H) (mm)
780x270x365
UI Dimensiuni(W*D*H) (mm)
805x194x285
UI Masa Net/Gross (Kg)
6.7/8.8
