Alimentare electrica (Ph-V-Hz)
220-240V,1Ph,50Hz
Racire sezoniera SEER (W/W)
7.4
Racire sezoniera Clasa eficienta energetica
A++
Incalzire sezoniera SCOP (W/W)
5.1
Incalzire sezoniera Clasa eficienta energetica
A+++
Incalzire sezoniera Temperatura de balans (℃)
-7
Temperatura limita pentru incalzire (℃)
-15
Compresor Model
KSN140D21UFZ
Motor ventilator UI Model
ZKFP-30-8-3
Motor ventilator UI Condensator electric (uF)
―
Motor ventilator UI Turatie(Hi/Mi/Lo) (r/min)
1130 / 900 / 800
Schimbator UI a.Numar spirale
2.0
Schimbator UI g. Numar de circuite
3
Debit aer UI (Hi/Mi/Lo) (m3/h)
840/680/540
Motor ventilator UE Model
ZKFN-34-10-1-3
Motor ventilator UE Turatie (r/min)
740/650
Schimbator UI a.Numar spirale_1
2.0
Control temperatura
Telecomanda
Temperaturi de lucru Intern (racire/incalzire) (℃)
17～32/0～30
Suprafata aplicatie minim maxim (m2)
24-35
Putere Racire Capacitate (Btu/h)
18000
(6200~21000)
Consum electric racire (W)
1550(140~2300)
Amperaj racire (A)
6.7(0.6~10)
Putere Incalzire Capacitate (Btu/h)
19000(4700~23000)
Consum electric incalzire (W)
1570(220~2350)
Amperaj incalzire (A)
6.8(0.95~10.2)
Racire sezoniera Pdesignc (kW)
5.2
Incalzire sezoniera Pdesignh (kW)
4.1
Putere max. consumata (W)
2500
Compresor Capacitate (Btu/h)
4385
Compresor Putere consumata (W)
1140
Compresor Amperaj in functionare (A)
7.50
Compresor Refrigerant oil/oil charge (ml)
VG74 440
Motor ventilator UI Putere (W)
36.0
Schimbator UI b.Pas tub(a)x pas linie(b) (mm)
21x13.37
Schimbator UI c.Spatiere (mm)
1.2
Schimbator UI e.Diametru tub (mm)
Φ7, tub canelat
Schimbator UI f.Lungime spira x inaltime x latime (mm)
750x189x26.74+750x105x26.74
Presiune sonora UI (Hi/Mi/Lo/Si) (dB(A))
42.5/36/26/20
Putere sonora UI (Hi) (dB(A))
56
UI Dimensiuni(W*D*H) (mm)
957x213x302
UI Ambalaj (W*D*H) (mm)
1035x295x380
UI Masa Net/Gross (Kg)
10/13
Motor ventilator UE Putere (W)
63
Schimbator UI b.Pas tub(a)x pas linie(b) (mm)_1
21x22
Schimbator UI c.Spatiere (mm)_1
1.3
Schimbator UI e.Diametru tub (mm)_1
Φ7,Inner groove tube
Schimbator UI f.Lungime spira x inaltime x latime (mm)_1
860x504x44
Schimbator UI g. Numar de circuite_1
4
Nivel presiune sonora UE (dB(A))
56
Putere sonora UE (dB(A))
63
UE Dimensiuni (W*D*H) (mm)
805x330x554
UE Ambalaj (W*D*H) (mm)
915x370x615
UE Masa Net/Gross (Kg)
32.7/35.4
Refrigerent Masa incarcatura (Kg)
1.08
Presiune de proiect (MPa)
4.3/1.7
Tevi refrigerent Diametru tevi refrigerent lichid/gaz (mm/inch)
Φ6.35(1/4’‘)/Φ12.7(1/2’‘)
Tevi refrigerent Lungime maxima traseu teava (m)
30
Tevi refrigerent Diferenta max. de nivel (m)
20
Exterior (racire/incalzire) (℃)
-15～50/-25～30
